K2 Energy Pytes V5 48V Backup Battery
This is an estimate only. Actual delivery times can vary with stock availability, courier delays, weather, public holidays and your location.
K2 Energy Pytes V5 Battery, Keep the Lights On, Mate!
Tired of power outages leaving the lights off, the fridge warming up and the household carrying on like the world’s ended? The K2 Energy Pytes V5 Battery provides reliable 51.2V lithium energy storage for home solar, backup power and off-grid systems, helping you store more of your solar energy and rely less on the grid.
With a compact rack-mounted design, smart monitoring and plenty of room to expand, it’s a practical way to keep the essentials running without dragging out a noisy generator every time the power has a little holiday. Keep your home powered and your worries down - check out the K2 Energy Pytes V5 Battery today.
Keep the lights on at home and add one to your cart today.
Why The K2 Pytes 48V Backup Battery May Be Right For You:
- Enjoy reliable backup power when you need it most, thanks to the 5.12kWh LiFePO₄ battery capacity, helping keep your important household appliances and equipment running during outages.
- Get more value from your solar system, with a higher charge and discharge rate that efficiently stores and delivers energy, so less of your hard-earned solar power goes to waste.
- Keep an eye on your battery without constantly checking the cupboard, using remote monitoring and upgrade capabilities, giving you better control and helping the system perform at its best.
- Start with the capacity you need and expand later, thanks to its scalable modular design that supports multiple batteries, allowing your energy storage system to grow alongside your household or business needs.
- Enjoy greater peace of mind around the home, with an advanced battery management system, integrated fire suppression and multiple safety protections, helping deliver secure and dependable energy storage for years to come.
K2 Pytes 5V Backup Battery Package Contents:
- K2 Energy Pytes V5 Alpha Plus 51.2V 5.12kWh LiFePO₄ Battery
- Wall Mount Bracket
- Communication Cable Set
- Power Cable Set
- Earthing Cable
- Mounting Hardware
- User Manual
- Warranty Information
K2 Energy Pytes V5 Battery User Manual:
K2 Energy Pytes V5 Battery Tech Specs
| Battery Chemistry | Lithium Iron Phosphate (LiFePO₄) |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Nominal Energy | 5.12kWh |
| Usable Energy | 4.86kWh (95% DoD) |
| Recommended Charge Voltage | 56.5V |
| Recommended Charge Current | 50A |
| Maximum Charge Current | 100A |
| Recommended Discharge Current | 50A |
| Maximum Continuous Discharge Current | 100A |
| Peak Discharge Current | 110A (15 seconds) |
| Depth of Discharge (DoD) | 95% |
| Cycle Life | Over 6,000 cycles @ 95% DoD |
| Round-Trip Efficiency | ≥95% |
| Communication | CAN, RS485, RS232 |
| Scalability | Up to 16 batteries in parallel |
| Cooling | Natural Convection |
| Installation | Wall-Mounted or Rack-Mounted |
| Ingress Protection | IP20 |
| Operating Temperature (Charge) | 0°C to 50°C |
| Operating Temperature (Discharge) | -10°C to 50°C |
| Storage Temperature | -20°C to 55°C |
| Integrated Protection | Advanced Battery Management System (BMS) with overcharge, over-discharge, overcurrent, short-circuit and temperature protection |
| Fire Protection | Integrated Aerosol Fire Suppression |
| Certifications | IEC62619, IEC61000, UN38.3, CE |
| Warranty | Up to 10 Years (subject to manufacturer's terms) |
K2 Energy Pytes V5 48V Backup Battery FAQs
1. How much usable energy is there?
5.12kWh nominal, of which 4.86kWh is usable at 95% depth of discharge. That 95% figure is unusually high, so you get more out of this battery than most that quote 80%.
2. How long will it last?
Over 6,000 cycles at 95% depth of discharge, with round-trip efficiency at or above 95%. For a home backup battery cycling daily, that's many years of service.
3. What can I connect it to?
It communicates over CAN, RS485 and RS232, so it integrates with most compatible inverters. Ring us on 1300 902 361 with your inverter model and we'll confirm compatibility before you order.
4. What are the charge and discharge limits?
Recommended charge voltage is 56.5V at 50A, with 100A maximum charge. Discharge is 50A recommended, 100A maximum continuous, and 110A peak for 15 seconds.
